The MP 37966 is a high-performance stainless steel pump end from the Flomax 15 series, designed for easy integration with various motor types. Built for reliability and versatility, this self-priming centrifugal pump offers a 3” NPT suction port with an ANSI 150 lb. flat flange, a 3” SAE 4-bolt discharge flange, and includes a Viton flapper valve for optimal sealing at the suction port. An optional 3” ANSI 150 lb. NPT flange discharge kit (Part No. 38647) is also available.
Crafted entirely from 316 stainless steel, the pump is highly resistant to corrosive fluids, making it ideal for demanding environments. Its durable construction includes a greased seal system that allows the unit to safely operate during short dry run conditions, helping extend seal life and overall runtime.
The MP 37966 is shipped as a complete and tested pump end, ready to be coupled with multiple driver configurations, including hydraulic motors, 184TC and 215C frame electric motors, or gas engines. For added flexibility, a bearing pedestal option is available for belt-driven or T-frame motor setups.
Technical Specifications:
- Suction/Discharge: 3" x 3" NPT
- Maximum Flow: 320 GPM
- Maximum Head: 145 ft
- Maximum Solids Handling: 0.625"
- Mount Type: Engine
The FLOMAX® 15 is widely used across industrial, agricultural, marine, and OEM sectors, supporting applications such as:
- Bilge and ballast transfer
- Washdown and fire suppression
- Chemical blending, spraying, and fertilizer pumping
- Bulk fluid transfer and nurse tanks
