The MP 38433 is a robust, high-performance stainless steel pump end from the FLOMAX 15 series, designed for self-priming centrifugal applications. This unit comes as a pedestal-style pump end only—without a motor—featuring a bare shaft for flexible integration with a range of drive systems.
Equipped with a 5-blade semi-open impeller measuring 6.0 inches in diameter, the pump ensures efficient fluid handling. It supports a 3-inch NPT suction port with a Viton flapper, and a 3-inch ANSI 4-bolt discharge flange, with the option to use an ANSI 150 lb. NPT discharge flange (part no. 38647).
Crafted from 316 stainless steel, the MP 38433 pump end offers excellent resistance to corrosive and chemically aggressive fluids, making it ideal for challenging environments. It features a well-lubricated mechanical seal, allowing safe operation under dry run conditions, thereby extending seal life and enhancing operational reliability.
This pump end is factory-assembled, performance-tested, and ready for integration with various drivers, including hydraulic motors, 184TC and 215C frame electric motors, and gasoline engines. A bearing pedestal is also available for T-frame motor or belt-driven setups.
Common Applications:
- Marine bilge systems
- Agricultural sprayers and applicators
- Fertilizer and pesticide transfer
- Fire-fighting support systems
- Industrial and OEM fluid transfer
- Washdown and blending operations
- Ballast and bulk liquid transfer
